ZKTeco ProFace X

Head Office: +92 51 2766289

Sales Manager: +92 300-0091469

Managing Director: +92 303-979779

Parameters

• Face Capacity

  30,000 (1:N) ;
  100,000 (Optional)

• Palm

  5,000 (Customized)

• Users / Card Capacity

  50,000

• Transaction Capacity

  1,000,000 (Optional 2,000,000)

• User Photo Capacity

  30,000

• Event Photo Capacity

  10,000

• Compatibility

  Security Relay Box
  Wiegand / RS485 Slave Reader with FP / RFID / Barcode / QR-code
  Software: ZKBio CVSecurity
  Mobile App: ZSmart (Optional)

• Hardware

  1GHz Dual Core Customized Computer Vision CPU
  1G RAM / 8G Flash
  8″ (400lux) IPS Touch LCD
  125KHz EM Reader / 13.56MHz MF (Optional)
  2MP WDR Low Light Camera
  Adjustable Light brightness LED
  Hi-Fi Voice
  Microphone
  Distance Detection Sensor
  Reset Button and Tamper Switch

• Access Control Interface

  Lock Relay Output / Alarm Output / Auxiliary Input / Exit Button / Door Sensorr

• Special Function

  IP68 & IK04
  0.3s High Speed Face Verification
  Live Face detection
  Communication Https Encrypted Optional
  Event Snapshot
  Video intercom
  ONVIF Protocol (Compatible with Profile S, Profile T, Profile G, Profile C, Profile Q & Profile A)
  SIP ProtocoI (Compatible with VT07-B01,Optional)

• Standard Function

  Access Levels, Groups, Holidays, DST, Duress Mode (Password), Anti-Passback, Record Query, Custom Wallpaper & Screen Saver, Tamper Switch Alarm

• Communication

  TCP / IP / Wiegand Input / Output / Wi-Fi (Optional) / RS485* / RS232*

• Additional Info



• Algorithm

  ZKFace 3.9 & ArmaturaPalm(Customized)

• Operating Temperature

  -30°C ~ 60°C (-22°F~ 140°F)

• Operating Humidity

  ≤ 93%

• Storage Temperature

  -40°C ~ +65°C

• Storage Humidity

  ≤ 93%

• Net Weight

  853 g

• Dimension

  227 * 143 * 26 mm (L*W*D)

• Power



• Operating Voltage

  12V DC

• Current Draw

  < 2,000 mA
