Panasonic Exchange TDE 600

Panasonic KX-TDA100D Hybrid IP-PBX System – Scalable Business Communication Solution

The Panasonic KX-TDA100D is a next-generation hybrid IP PBX system designed for small to mid-sized businesses seeking a powerful, flexible, and scalable communication platform. Featuring a modular design and a sleek black chassis, this system blends effortlessly into modern office environments while offering robust voice and networking features to meet today’s demanding communication needs.

Key Features:

• ✅ Hybrid System Design – Supports both traditional analogue and modern IP telephony, ensuring future-ready scalability.

• ✅ Stylish Modular Chassis – Compact, black casing with modular slot design for easy customization and expansion.

• ✅ Advanced Call Management – Includes call forwarding (FWD), Do Not Disturb (DND), call waiting, and call pickup across any extension.

• ✅ Direct Inward Dialing (DID/DDI) – Enable callers to reach specific users directly without receptionist assistance.

• ✅ Multiple Subscriber Number (MSN) – Flexible numbering and ringing service for diverse business needs.

• ✅ CLI and Call Indication – Caller Line Identification (CLI), connected name/number presentation (CLIP/COLP, CNIP/CONP), and incoming call alerts.

• ✅ Speed & Memory Dialing – One-touch, speed, and quick dialing for enhanced productivity.

• ✅ Executive Call Control – Features like busy override, second call notification, and call monitoring ensure high-level communication management.

• ✅ Integrated Music and Messaging – Includes Background Music (BGM), Outgoing Message (OGM), and Music on Hold (MOH) options.

• ✅ Multi-Zone Paging & Door Integration – Internal/external paging, support for doorphones, sensors, relays, and door openers.

• ✅ Networking Ready – VoIP, VPN, QSIG, NDSS, and centralized voicemail support for multi-site operations.

• ✅ Hands-Free & EHS Support – Full duplex speakerphone and headset compatibility with Electronic Hook Switch (EHS).

• ✅ DISA & Centralized Voice Mail – Direct Inward System Access and ICD group compatibility enhance call routing efficiency.

• ✅ Eco-Friendly Operation – Designed for high efficiency and low power consumption in office environments.

Technical Specifications:

System Capacity:

• Trunk/Extension Card Slots: Up to 7

• Extension Types:

  • SLT: 176

  • Digital (KX-DT300 / KX-T7600 Series): 128

  • IP-PT: 104

  • Max Combinations: 176 Extensions*

* Example: 104 Digital + 48 IP Phones + 24 SLTs

Supported Devices:

• DSS Consoles: 8

• Voice Processing Systems: 2

• Doorphones: 16

• Door Openers: 16

• External Sensors/Relays: 16

Connectivity:

• Control Bus: 16-bit, 8 MHz (10 MB/s)

• Communication Bus: H.100 (1024 time slots)

• Serial Port: RS-232C (up to 115.2 kbps)

• USB Port: 1

• Extension Cable: 1-pair or 2-pair (SLT, DPT, DSS, PT-interface)

Voice Capabilities:

• Conference Calls: Up to 4 x 8-party or 10 x 3-party

• MOH: 2 Ports (Internal/External, Adjustable Volume -11 dB to +11 dB)

• Paging: Internal & External (2 Ports, Adjustable Volume)

Other Specs:

• Dialing Types: Dial Pulse (10/20 pps), DTMF

• Ring Frequency: 20 Hz / 25 Hz (Selectable)

• Trunk Loop Limit: Max 1600 Ohms

• Operating Environment:

  • Temperature: 0°C to 40°C

  • Humidity: 10% to 90% (Non-condensing)

Physical Dimensions:

• Dimensions: 334 mm (W) × 390 mm (H) × 270 mm (D)

• Weight: Under 12 kg (Fully Equipped)

Ideal For:
Businesses seeking a powerful yet flexible PBX system with advanced call handling, IP telephony support, and easy expansion for future growth. The Panasonic KX-TDA100D is the smart choice for organizations looking for a robust, future-proof telecommunication infrastructure.
