UAC-T112 Series – 2MP HD Analog IR Bullet Cameras
Models: UAC-T112-F28 (2.8mm) / UAC-T112-F40 (4.0mm)
The UAC-T112 Series offers reliable high-definition surveillance with excellent low-light performance and flexible analog video format support. With durable IP67-rated housing, smart IR, and multilingual OSD menu, these cameras are perfect for both indoor and outdoor security applications.
Key Features
-
2MP CMOS Sensor delivering Full HD 1080P resolution
-
Multiple Output Formats: TVI, AHD, CVI, CVBS via BNC
-
Smart IR with up to 20m illumination distance
-
IR-Cut Filter (ICR) for True Day/Night functionality
-
Digital Wide Dynamic Range (DWDR) and 2D DNR
-
OSD Menu in 11 Languages
-
Flexible Mounting: Wall, Pole, Corner, and Pendant options
-
Weatherproof Design: IP67-rated enclosure
-
Surge Protection: 4KV for both power and video interfaces
-
Flip Function: Supports 180° horizontal and vertical flip
Camera Specifications
| Specification |
UAC-T112-F28 |
UAC-T112-F40 |
| Sensor |
1/3″ CMOS |
1/3″ CMOS |
| Max Resolution |
1920×1080 (1080P) |
1920×1080 (1080P) |
| Minimum Illumination |
0.02 lux (F2.0, AGC ON); 0 lux (IR ON) |
0.02 lux (F2.0, AGC ON); 0 lux (IR ON) |
| Lens |
2.8mm |
4.0mm |
| Lens Mount |
M12 |
M12 |
| Angle of View |
H: 90.5° / V: 49.6° / D: 109.5° |
H: 80.2° / V: 40.7° / D: 90.5° |
| IR Distance |
Up to 20m |
Up to 20m |
| IR Lifetime |
≥60,000 hours |
≥60,000 hours |
Video Performance
Image Enhancement
-
Exposure Modes: Global (default), BLC, HLC, DWDR
-
Day/Night Modes: Auto (default), Day, Night
-
Digital Noise Reduction: 2D
-
White Balance: Auto (default), Manual
-
WDR: Digital WDR (DWDR)
-
Smart IR: Supported
-
Image Flip: 180° horizontal & vertical
General Specifications
| Feature |
Details |
| Power Supply |
DC 12V ±25% |
| Power Consumption |
Max 2.88W |
| Interface |
5.5mm Power / BNC Video Output |
| Mounting |
Wall, Pole, Corner, Pendant |
| Material |
Plastic |
| Dimensions |
Φ118mm × 96mm |
| Weight |
182g (0.401 lb) |
| Operating Temperature |
-30°C to 60°C (-22°F to 140°F) |
| Humidity |
≤95% RH (non-condensing) |
| Ingress Protection |
IP67 |
| Surge Protection |
4KV (Power & Video) |
| OSD Languages |
11 Languages (EN, DE, ES, FR, IT, JP, KR, PL, PT-BR, RU, TR) |
Certifications
-
EMC: CE-EMC, FCC Part 15B
-
Safety: CE-LVD (EN 62368-1)
-
Environmental: RoHS, WEEE
-
Protection: IP67 (IEC 60529)
-
